Si-met
Dry etching and metallization for Si-processes
 |
An Applied Materials P5000 dry etcher (to the left) and
a MRC sputtering tool (to the right)
|
 |
|
Chamber A:
etching of SiN and SiO2
Chamber B:
etching of Al, TiW, Al(Si,Cu) and TiN
Chamber C:
etching of poly-Si, poly-SiGe, and
c-Si
|
|
Deposition of metal and metal alloys films by the sputter process.
Deposition of nitrides by reactive sputtering with N2, e.g. TiN.
|
All pictures can be viewed in larger format, just click on them.
